Zero Loss Drain Valves
Mechanical Float Zero-Loss Condensate Drain
Mechanical float-operated zero-loss condensate discharge for compressed-air systems, with no external electrical supply required.
Specifications
- Product type
- Mechanical float zero-loss drain
- Model
- AZ-EAD-250-G1
- Inlet
- G1
- Outlet
- G1/4
- Air return port
- G1/2
- Working pressure
- 1-12 bar
- Max. temperature
- 60°C
Mechanical float-operated zero-loss condensate discharge for compressed-air systems, with no external electrical supply required.
Highlights
• Fully mechanical: float-operated discharge without external electrical power.
• Zero-loss principle: evacuates condensate while retaining system pressure.
• High capacity: suitable for dryer, centrifuge and compression-heat service.
Application
Recommended for air receivers, dryers, centrifuges and compression-heat systems requiring mechanical zero-loss condensate discharge. Max. dryer capacity: ≥80 m³/min.
Specifications
AERZIX Model | Operating Principle | Condensate Inlet | Condensate Outlet | Air Return Port | Working Pressure | Max. Temperature | Housing Material |
AZ-EAD-250-G1 | Mechanical float | G1 | G1/4 | G1/2 | 1-12 bar | 60°C | Aluminum alloy |
