Threaded Compressed Air Filters
AZ-CF-T-XF Series Threaded Compressed Air Filters
AZ-CF-T-XF Series threaded compressed air filters are used for the filtration of dust, lubricants, oil mist and condensed water from compressed air. The filter housing can be produced in 2 optional materials: aluminum alloy and carbon steel, with color options of white or blue. An alumin
Specifications
- Product type
- Compressed air filter
- Series
- AZ-CF-T-XF Series Threaded Compressed Air Filters
AZ-CF-T-XF Series threaded compressed air filters are used for the filtration of dust, lubricants, oil mist and condensed water from compressed air. The filter housing can be produced in 2 optional materials: aluminum alloy and carbon steel, with color options of white or blue. An aluminum alloy housing is suitable for pneumatic systems and a working pressure of less than 1.6MPa. A carbon steel housing is ideal for larger filters and high-pressure systems, with the highest filtration grade of 0.01μm.
Aluminum alloy housing
Carbon steel housing
Filter Grade | Filtration rate | Efficiency | Residual oil content at an inlet of 3 mg/m3 |
AZ-CF-T-XF9 | 3μm | 99% | 5 |
AZ-CF-T-XF7 | 1μm | 99% | 1 |
AZ-CF-T-XF5 | 0.01μm | 99% | 0.01 |
AZ-CF-T-XF3 | 0.01μm | 99% | 0.001 |
AZ-CF-T-XF1 | 0.01μm | 99% | 0.001 |
Technical data for filter housing | — |
Operating pressure max. | 40 bar |
Operating temp. Max. | 120℃ |
Material housing | Carbon Steel |
Surface finish | Epoxy resin |
Sealing | Perbunan |
Optional accessories
• Direct-Mount differential pressure gauge
• Differential pressure gauge with pipe mounting bracket
• External float drain
• Built-in automatic drain
• Electronic drain
• Magnetic level gauge
